FEATURES
BASIC PANP-S/R/P
-
Power Requirement - Vcc +5v 5% 350ma
-
RS-485 Load - 1/64th
-
3 Outputs 0 to 5v Hi >Vcc-0.2 @100ma
-
1 Beeper Output TTL 4khz
-
1 Status Output TTL
-
Baud Rates 9.6 to 115k
-
Unique Electronic Serial Number ID
-
No jumpers, switches or pots
-
Crystal Controlled Timing
-
Transmit and Receive Led Indicators
-
Modular 4 pin RS-485 connectors (2)
-
Modular 6 pin RS-232 connector
-
Can Daisy Chain RS-485
-
10 pin keyboard interface connector
-
6 pin card reader interface connector
-
Dallas 80C320 25mhz Processor (8051)
-
32k byte static memory
-
128k byte flash memory
-
RS-232 to RS-485 conversion
-
4x20 backlighted LCD display
-
Automatic Temperature Compensation
-
Wide temperature range -20 to 70 C
RELAYS PANP-R/P
-
Two Relays - Form C SPDT 10a 250vac
-
Pluggable Screw terminal connectors
|
OPTO-ISOLATION PANP-P
-
Power 12-24vac/12-30vdc 2-3w
-
+5v user power can power a SMX32/16-S
-
Automatic Power Fuse Reset
-
RS-485 Super Static protection
-
RS-485 Fusing for Overvoltage
-
RS-485 Automatic Fuse Reset
-
Opto-Reflective Security sensor
-
4khz Beeper
-
Auto RS-485 termination
-
RS-485 Status LED
-
User Status LED
-
Plugable Screw Terminal Net Connectors
-
Lightning Protection
RS-485 PROTOCOL
-
Packet System
-
Address select with parity bit (bit9)
-
Device Code + s/n = Address (32b)
-
Checksum on all packets
-
Packet format device dependent
SOFTWARE
-
Flash Boot - Update over Network
-
Keyboard and Display Handler
-
Forth Development Enviornment
-
Custom Applications
|
..
